LEDskin® curved LED modules
Innovative and modular LED wall with curved modules.
LEDskin® is a revolutionary product designed for stand construction . LEDskin® fascinates by the endless possibilities and guarantees a quick construction and a nice look of your stand. The wall with curved modules can be used indoors and can be perfectly integrated into the b62 frame system.
Best quality for fast installation
Manufactured by the premium manufacturer INFiLED for frequent use at trade fairs and other events. Durable and reliable.
With the curved LED modules and convex or concave LEDskin® frames, you can even integrate curves that fit perfectly into the aluminium frame system.
A beMatrix stand combines the advantages of a modular system with the possibilities of tailor-made solutions. Almost any shape, contour and design is conceivable
and can be easily created. With a single frame you can realize all kinds of stand concepts.
- Resolution: Pixelpitch 2,5mm
- LEDskin modules can be integrated into the beMatrix frame system
- The modules have a very high light intensity and contrast.
- The alignment of the LED tiles is done by magnets and manual connectors.
- The holes in the beMatrix frame also serve as a practical cable duct.
- LEDskin® frames can be easily covered with textile on the back using Velcro.
- The sides of the LEDskin® modules can be covered with cover profiles.
- The LED modules can be easily replaced at the front.
- A single LEDskin® module weighs only 8.8 kg and has a practical handle.
- Each LED cabinet is packaged in a shock-absorbing foam protector.
- The LED panels are transported in a light and handy flight case.
Angabe | LEDskin 2.5 Concave | LEDskin 2.5 Convex |
---|---|---|
Pixelabstand | 2,50 mm | 2,50 mm |
Pixeldensity | 149.844 pixels/m² | 149.844 pixels/m² |
Cabinet Auflösung | 276×192 pixels | 312×192 pixels |
Cabinet Maße | 496x496x496 mm | 496x496x496 mm |
Cabinet Gewicht | 8,8 kg | 8,8 kg |
Helligkeit | 1200nits | 1200nits |
Maximaler Energieverbrauch | 100w/panel | 100w/panel |
Durchschnittlicher Energieverbrauch | 33w/panel | 33w/panel |
Einblickwinkel | 110°/110° | 110°/110° |
Betriebsstromversorgung | AC110-220V 50-60Hz | AC110-220V 50-60Hz |
Betriebstemperatur | Betriebstemperatur −10℃~+45℃ | Betriebstemperatur −10℃~+45℃ |
Refresh Rate | <3.840Hz (einstellbar) | <3.840Hz (einstellbar) |
Schutz-Klassifizierung | IP30 | IP30 |
Receiver Karte | NOVASTAR Amor8S | NOVASTAR Amor8S |
Zulassungsprüfung | CE, ETL, FCC, RoHS | CE, ETL, FCC, RoHS |
